Plant List
2x Matsuura MX-520 5 Axis Machining Centre
Travel: X / Y / Z: 630 / 560 / 510 mm
Travel: A / C: -125° ~ +10° / 360°
Working Surface: ø300 STANDARD mm
Loading Capacity: 200 kg
Spindle Speed: 12,000 min⁻¹ : BT40 STANDARD
Rapid Traverse: X / Y / Z: 40 m/min
Number of Tools: 60 &90
Coolant: 20 bar High Pressure Coolant through Spindle
Tool Changing Time: 1.1 secs
NC Control: Matsuura G-Tech 31i / Touch Screen Control
Tool Setting: Renishaw NC4 Tool Breakage Detection
Inspection: Renishaw RMP600 Wireless In Cycle Inspection Probe
Haas VF2SS-YT Vertical Machining Centre
Travel: X / Y / Z: 762 / 506 / 508 mm
Table Surface: X / Y: 914 / 457 mm
Loading Capacity: 680 kg
Spindle Speed: 12,000 min⁻¹ : BT40 Standard
Rapid Traverse: X / Y / Z: 35 m/min
Number of Tools: 30
Coolant: 20 bar through Spindle
Tool Change Time: 2.2 sec (chip to chip)
4th Axis: Haas Ø160 Fully Programmable
Haas Super Mini Mill 2 Vertical Machining Centre
Travel: X / Y / Z: 508 / 406 / 356 mm
Table Surface: X / Y: 1016 / 356 mm
Loading Capacity: 227 kg
Spindle Speed: 10,000 min⁻¹
Rapid Traverse: X / Y / Z: 38.1 m/min
Number of Tools: 24 + 1
4th Axis: Haas H10 Fully Programmable
DMG-MORI ecoTurn 310 CNC Turning Centre
Travel: X / Z: 182.5 / 455 mm
Max Bar Diameter: 51 mm
Max Turning Diameter: 200 mm
Max Spindle Speed: 5000 rpm
Rapid Traverse: X / Z: 30 / 30 m/min
Number of Tools: 12
Number of Driven Tools: 12
Other Shop Floor Equipment
- Harrison Alpha 400 Plus Centre Lathe
- Hardinge HLV Lathe
- Jones and Shipman 540P Surface Grinder
- Tapping machines
- Edgecam Advanced Milling Solid CAD CAM with Designer
- OneCNC 3d Expert Programming suite.
- CGTech Vericut CNC verification software
- Aberlink Axiom Too 600 CNC CMM with CAD Comparison software module. Measuring envelope 640 x 600 x 500
- Mitutoyo Shadow Graph
- Various Micrometers,
- Bore Micrometers
- Thread gauges
- Brown & Sharp comparator.
- GPR are Certified to BS EN ISO 9001:2015 standard
